Main specifications
LINE HONING MACHINE LBH100
Main Bearing Bore Diameter Range:46-178 mm(1.800-7.000 in)Special tooling required for 127-178 mm(5.000 to7.000in).
E-mail: sales@apsmachinery.com
Consult Now
Introduction
Accessory
Download
Viedo
Main Bearing Bore Diameter Range:46-178 mm(1.800-7.000 in)Special tooling required for 127-178 mm(5.000 to7.000in).
Capacity:V blocks, both 90 and 60; overhead and L.head in-line blocks; up to 1140 mm(45 in)long, 710mm (28 in) from head deck to main bearing centerline.
Minimum stock removal, usually less than .003"(.076mm)off the caps compared to as much as .010"(.254mm) with boring.
Maximum precision, corrects distortion caused by warpage and cap stretch Meets or exceeds original factory accuracy for alignment, roundness and size.
Fast, easy setup.
Ease of operation, no special training required Profitable: Make $90-$120 in 30 minutes on a typical V-8 block.
Lifetime application service with every machine purchase.
Model | LBH100 |
Diameter of honing hole | 46-178mm |
Rotational speed of spindle | 150r/min |
Electric motor power of spindle | 1.5KW |
Cooling pump power | 0.12KW |
Inner working area size(L*W*H)mm | 1140*710*710(mm) |
Overall dimensions(L*W*H) mm | 3200*1480*1920(mm) |
Max travel of spindle | 660mm |
Minimum amount of Coolant | 130L |
Maximum amount of Coolant | 210L |
Weight of main machine(approx) | N.W 670kg G.w800kg |
-
